Stands up to even extreme weather.
With an IP67-rated camera body, the C3TN is both dust- and water-resistant. It can stand steady even against the toughest weather conditions – whether it’s rainy, stormy or snowy.
C3TN
Home protection in the simplest way.
Specification
-
Specifications Model CS-C3TN(2MP) Camera Image Sensor 1/2.7”Progressive Scan CMOS Minimum Illumination 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR Shutter Speed Self-adaptive shutter Lens 2.8 mm @ F2.0, view angle: 106° (Horizontal), 122°(Diagonal) Lens Mount M12 DNR 3D DNR WDR Digital WDR Compression Video Compression H.265 / H.264 Video Bit Rate Ultra-HD; HD; Standard. Adaptive bit rate. Image Max. Resolution 1920 × 1080 Frame Rate Max: 30fps; Self-Adaptive during network transmission Network Wi-Fi Pairing AP Pairing Protocol EZVIZ Cloud Proprietary Protocol Interface Protocol EZVIZ Cloud Proprietary Protocol General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark Max. Bitrate 2M Interface Storage Micro SD card slot (Max. 256 GB) Wired network RJ45 × 1(10M/100M Adaptive Ethernet Port) Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n Frequency Range 2.4GHz ~ 2.4835 GHz Channel Bandwidth Supports 20MHz Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Transmission Rate 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps General Operating Conditions -4°F to 122 °F (-20ºC to 50ºC ); Humidity 95% or less ( non-condensing) Power Supply DC 12V/1A Power Consumption Max. 6W IP Grade IP 67 Night Vision Distance (Black/White Night Vision Mode) Max. 30 m (98 ft) Dimensions 72 × 72 × 152 mm (2.83 × 2.83 × 5.98 inch) Packaging Dimensions 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch) Net Weight 253 g (8.9 oz) In the box In the box - C3TN Camera - Drill Template - Screw Kit - Waterproof Kit - Power Adapter - Regulatory Information - Quick Start Guide Certifications Certifications CE / FCC / UL / RoHS / WEEE
